M12, female, straight, L‑coded, 4‑pos., shielded, metal housing, screw terminal

M12, female, straight, L‑coded, 5‑pos., shielded, metal housing, screw terminal

9,21 €

ℹ️ Component product
This product can only be purchased as part of a module configuration.

Go to Configurator

Field-wirable M12 circular connector with straight female L-coded interface, 5 positions, screw connection, shielded metal housing. Designed for 8–10 mm cables in industrial power applications.

Category:

Description

A field-wirable M12 circular connector featuring a straight female L-coded design with 5 positions.
It is equipped with a screw-terminal connection and supports cable diameters from 8 to 10 mm.
With its nickel-plated brass housing and IP67 protection (mated), this connector is ideal for compact high-current power distribution in industrial settings.

Feature Description
Connector type M12 circular, female
Orientation Straight (180°)
Coding L-coded (power)
Number of positions 4
Connection method Screw terminal (field-wirable)
Rated voltage 63 V DC
Rated current 16 A
Shielding Yes (metal housing)
Housing material Brass, nickel-plated
Coupling nut material Zinc die-cast, nickel-plated
Contact material Brass, gold-plated
O-ring material NBR
Cable diameter 8–10 mm
Wire gauge Up to 14 AWG
Protection class IP67 (mated)
Ambient temperature –25 °C to +85 °C

Benefits:

  • High current (16 A) support in compact L-coded M12 format
  • Rugged, shielded housing with IP67 protection for industrial environments
  • Field-wirable via secure screw terminals, supports large cable diameters

Compliance:

  • RoHS- and REACH-compliant
  • Conforms to IEC 61076-2-111 (L-coded M12 standard)
