M12, female-to-male cordset, straight, A‑coded, 4‑pos., unshielded, molded cable

M12, female-to-male cordset, straight, A‑coded, 4‑pos., unshielded, plastic housing, molded cable

15,95 €

Pre-molded M12 A-coded cordset with straight female and male connectors, 4 positions, non-shielded, 2 m PVC cable – ideal for reliable fieldbus signal transmission.

Category:

Description

A 2 m pre-molded M12 cordset designed for reliable industrial signal connections.
It features a straight female-to-male A-coded assembly with 4 contacts, using rugged PVC cable.

Feature Description
Product type M12 female-to-male cordset (pre-molded)
Orientation Straight (180°)
Coding A-coded (signal)
Number of positions 4
Shielded No
Rated voltage 250 V
Rated current 4 A
Contact resistance ≤ 5 mΩ
Insulation resistance ≥ 100 MΩ
Pollution level 3
Wire gauge 0.34 mm² (≈ 22 AWG)
Cable OD ≈ 5.2 mm
Cable material Black PVC
Protection class IP67 (mated)
Ambient temperature –25 °C … +85 °C
Standard IEC 61076‑2‑101

Benefits:

  • Pre-molded assembly ensures consistent quality and ease-of-installation
  • A-coding and 4-pin contacts ideal for sensor and fieldbus signals
  • IP67-rated with robust PVC jacket suited for aggressive environments

Compliance:

  • RoHS and REACH compliant
  • Conforms to IEC 61076‑2‑101
